Description
The Xerox G4 Pro 40.5K/60kpV is a high-efficiency, three-phase solar inverter designed for commercial use. It delivers 40,500 W of AC power and supports up to 60,000 Wp of PV array input (150% oversizing) . With a wide MPP voltage range (180V?1000V) and 4 independent MPPT inputs , it ensures maximum energy harvest even under partial shading thanks to ShadeSol technology . The unit features IP66 protection , making it suitable for both indoor and outdoor installations, and includes smart monitoring via the Ai Solar App . It offers advanced safety features and active cooling for reliable long-term performance.
Download DataSheet
| Model | G4 Pro 40.5K/60kpV |
| Installation Method | Quick and easy-to-install with standard tools |
| Setup & Monitoring | Smart setup, commissioning and monitoring via Ai Solar App |
| Design | Compact wall mount |
| Standards | IEC62109-1, IEC62109-2, IEC62727, IEC62683, IEC62116 |
| PV Array Oversizing (STC) | Up to 150% (60,000 Wp) |
| Protection Rating | IP66 (suitable for indoor and outdoor use) |
| MPP Voltage Range | 180 V ? 1000 V |
| ShadeSol Technology | Yes (improves generation under non-ideal conditions) |
| Max Altitude | 3000 m |
| Rated Active Power | 40,500 W |
| Rated Apparent Power | 40,500 VA |
| AC Nominal Voltage | 230 V / 400 V |
| AC Voltage Range | 160 V ? 300 V |
| AC Grid Frequency | 50 Hz |
| AC Grid Frequency Range | 45 Hz ? 55 Hz |
| Rated Output Current | 63.8 A |
| Input Voltage at MPP Range | 180 V ? 1000 V |
| Minimum Input Voltage | 160 V |
| Initial Feed-in Voltage | 200 V |
| No. of Independent MPPT Inputs | 4 |
| Strings per MPPT Input | A:2; B:2; C:1; D:1 |
| Max Efficiency | 98.70% |
| European Efficiency | 98.30% |
| Adjustable Power Factor Range | 0.8 Leading to 0.8 Lagging |
| Harmonic Distortion (THD) | < 3% at rated output |
| Ground Fault Monitoring | Yes |
| DC Switch | Yes |
| Grid Monitoring | Yes |
| DC Reverse Polarity Protection | Yes |
| AC Short Circuit Protection | Yes |
| Residual Current Monitoring Unit | All-pole-sensitive |
| Anti-Islanding Protection | Yes |
| Surge Protection | Yes |
| Protection Class (IEC 62109-1) | AC: III; DC: II |
| Overvoltage Category | II |
| Dimensions (W x H x D) | 574 mm x 513.5 mm x 234.5 mm |
| Weight | 29.5 kg |
| Operating Temperature Range | Not specified |
| Self-consumption (at night) | < 1 W |
| Topology | Non-isolated |
| Cooling Concept | Active cooling |
| Climatic Category (IEC 60721-3-4) | 4K4H (non-condensing) |
| Mounting Type | Wall-mount bracket |
| DC Connection | Plug-in connector |
| AC Connection | Plug-in connector |
| LED Indicators | Status / Fault / Communication |
| Communication Interface | RS485 / Wi-Fi / LAN / 4G |
